MIFARE 4K Card Custom RFID Cards

Our factory’s hottest selling NXP chip card, often referred to as “MIFARE 1K”

NXP® has developed the MIFARE® MF1ICS50 to be used in a contactless smart card according to ISO/IEC 14443 Type-A. The MF1ICS50 is designed for simple integration and user convenience. Which could allow complete ticketing transactions to be handled in less than 100 ms. Thus, the MF1ICS50 card user is not forced to stop at the reader leading to high throughput at gates and reduced boarding times onto buses. Hotel keycard, cushless payment card, access control card etc..

MIFARE 4K Card Custom RFID Cards NXP MIFARE Classic

Physical Specifications

Card Dimensions: 86×54mm
Card Thickness: about 0.88 mm
Material Selections:
White Core PVC
White Core PET
Wooden
Color Core PVC (Red/Yellow/Black/Blue etc.)

Operating Limits:
-40 to +100°C 20% to 90% RH
Storage Limits:
-25° to +90°C 20% to 90% RH

IC type: MIFARE Classic®EV1 4k (S70)
UID: 7 Bytes UID or 4 Bytes NUID
EEPROM: 4 kB
Data Transfer Rate: 106 Kbit/s
Capacitance: 14.9-19 pF
Support protocols:
ISO/IEC 14443-A
Operating Frequency: 13.56 MHz
Data retention: 10 years
Write endurance: 100,000 cycles
Anti-Collision Function: Yes

Applications

Hotel key card
Public transportation
Access management
Electronic toll collection
Car parking
School and campus cards
Employee cards
Internet cafés
Loyalty
